Orbea Oiz M20 TR

Orbea Oiz M20 TR
  • Color: Coral/Black
  • Color: Lichen Green/Black
  • Color: Anthracite Glitter/Black
Please select options
Order now and pick up in-store for free


Oiz is familiar with the hard work it takes to reach summits, leaderboards, and podium steps. We don't need to fabricate a pedigree for this phenomenon—two world championships prove Oiz is a thoroughbred. Oiz and serious cross-country are synonymous; its presence on the World Cup is undeniable. It's the lightest, stiffest, and most efficient machine available—whether you pin on a number or take it up to the highest peak on your afternoon ride. Oiz has what you need to get there—there is no better weapon to aim for the top.


Frame Orbea Oiz Carbon OMR AlloyLink Boost PF Taper UFO2 I-Line
Fork Fox 34 Float SC Performance 120 Grip Remote Push-Unlock QR15x110
Headset Acros Alloy 1-1/8 - 1-1/2" Integrated
Axles Front: 110 x 15mm thru-axle
Rear: 148 x 12mm thru-axle
Rims/Wheels DT Swiss X-1900 Spline 25c TLR 15/110mm CL
Tires Maxxis Rekon Race 29 x 2.35" 120 TPI Exo TLR
Crankset SRAM GX Carbon Eagle Dub Lunar Boost 32t
Chain SRAM GX Eagle 12-Speed
Rear Derailleur SRAM GX Eagle Lunar
Cassette/Rear Cogs SRAM XG-1275 Eagle 10-50t 12-Speed
Shifters SRAM GX Eagle Lunar
Handlebars OC1 Flat 31.8mm 740mm
Stem OC1 31.8mm interface -7º
Brakes Shimano M6100 Hydraulic Disc
Pedals Sold separately
Saddle Fizik Taiga S-alloy rail
Seat Post OC2 Dropper 31.6mm 125mm travel
Accessories & Extras Orbea OC chainguide
OC Squidlock 3-position remote lockout

* Subject to change without notice.


Part Numbers

Option UPC MPN Store SKU
Coral/Black / Small 08434446757617 L24116LE OIZ15807823K
Coral/Black / Medium 08434446757648 L24117LE OIZ15926433K
Coral/Black / Large 08434446757679 L24119LE OIZ15956025K
Coral/Black / X-Large 08434446757709 L24121LE OIZ16238157K
Lichen Green/Black / Small 08434446757624 L24116LF OIZ15610934K
Lichen Green/Black / Medium 08434446757655 L24117LF OIZ15469434K
Lichen Green/Black / Large 08434446757686 L24119LF OIZ15700093K
Lichen Green/Black / X-Large 08434446757716 L24121LF OIZ16765599K
Anthracite Glitter/Black / Small 08434446757600 L24116LD OIZ15798238K
Anthracite Glitter/Black / Medium 08434446757631 L24117LD OIZ15876977K
Anthracite Glitter/Black / Large 08434446757662 L24119LD OIZ15466877K
Anthracite Glitter/Black / X-Large 08434446757693 L24121LD OIZ16449337K
