Orbea Terra M20-D 1X

Orbea Terra M20-D 1X
  • Color: Anthracite/Black
  • Color: Black/Red
  • Color: Yellow/Black
Please select options


Of course you’re not lost, you just aren’t quite sure if this road is the quickest route to the next ridge. The weather is great, you’ve got all day, and you’re riding Terra, so keep the wheels rolling. If route-finding, taking the long way home, and straying from the beaten path are your ideas of fun, there is no better tool than Terra for unlocking your desire to explore.

Terra can fill several roles - Gravel, Road, CX, Winter Training, or Commuting. Tire clearance and the ability to mount accessories like mud guards, combined with a functional All-Road Geometry means that Terra can change with the seasons.

- Control in a variety of circumstances. Terra is designed to be at home on dirt, gravel, or just about anything else you might encounter.
- Terra ergonomics work for cyclocross, all-day rides, and the occasional long training day on the road.
- Handling is precise and intuitive. Angles and dimensions are considered carefully across a range of sizes to maximize rider comfort.

- Orbea Terra carbon OMP disc frame and fork
- Fulcrum Racing 900 DB wheelset
- 11-speed - Shimano XT/RX components
- Shimano RX hydraulic disc brakes


Frame Orbea Terra carbon OMP disc, monocoque construction, tapered 1-1/8-inch - 1.5-inch, PF30, power meter compatible, Thru Axle 12mm x 142mm rear, thread M12x P1.5, internal cable routing, EC/DC compatible, SP 27.2mm
Fork Orbea Terra OMP carbon disc fork, full carbon steerer, tapered 1-1/8-inch - 1.5-inch, carbon dropouts, Thru axle 12mm x 100mm, thread M12xP1.5, MMS system
Headset FSA 1-1/8 - 1-1/2-inch Integrated Carbon Cup ACB Bearings
Axles Front: Orbea Road 12x100mm
Rear: Orbea Road 12x142mm
Wheels/Rims Fulcrum Racing 900 DB
Tires Vittoria Terreno Dry CX-Gravel G2.0 TNT 700x38c
Crankset Shimano GRX RX810
Chainrings 40T
Chain KMC X11-EL
Rear Derailleur Shimano RX812 GS Direct mount
Cassette/Rear Cogs Shimano XT M8000 11-40T 11-Speed
Shifters Shimano ST-RX810
Handlebars OC1 All Road Handlebar reach 80mm, drop 125mm, flare 12º
Tape/Grips Orbea Anti-Slippery/Shock Proof
Stem OC2 Road stem -8º
Brakes Shimano ST-RX810
Saddle Selle Italia X3 Flow
Seat Post OC2 27.2 Offset 20

* Subject to change without notice.


New Orbea Terra

Part Numbers

Option UPC MPN Store SKU
Anthracite/Black / X-Small 08434446562761 K11351GJ TER19570430K
Anthracite/Black / Small 08434446562808 K11353GJ TER18487822K
Anthracite/Black / Medium 08434446562846 K11355GJ TER18122186K
Anthracite/Black / Large 08434446562884 K11357GJ TER18541967K
Anthracite/Black / X-Large 08434446562921 K11360GJ TER19521926K
Black/Red / X-Small 08434446562747 K11351GG TER19229794D
Black/Red / Small 08434446562785 K11353GG TER18195555D
Black/Red / Medium 08434446562822 K11355GG TER18786544D
Black/Red / Large 08434446562860 K11357GG TER1872373D
Black/Red / X-Large 08434446562907 K11360GG TER19311184D
Yellow/Black / X-Small 08434446562754 K11351GH TER19983632K
Yellow/Black / Small 08434446562792 K11353GH TER18450355K
Yellow/Black / Medium 08434446562839 K11355GH TER18431444K
Yellow/Black / Large 08434446562877 K11357GH TER18954941K
Yellow/Black / X-Large 08434446562914 K11360GH TER19210371K
